Heating Plate Magnetic Stirrer is a kind of through the electric heating plate heat radiation to provide heat source to the material, stirring through the magnetic suction to drive the stirrer to stir the material. It can be used for liquid-liquid mixing, solid-liquid suspension, gas-liquid or liquid-liquid dispersion under constant temperature. It is widely used in laboratory, pharmaceutical, chemical, food, biotechnology and other industries.
Product Advantages and Features:
- Adopting plane heating, heating plate ceramic treatment, anti-corrosion, high temperature does not change color.
- Dual-channel design for heating and stirring; can be controlled separately.
- Internal and external temperature sensors, can measure the temperature of the material control.
- DC permanent magnet motor, low noise, high torque, long service life.
| Product Name | Plate Magnetic Stirrer | |||||||
| Model | MSP-2C | MSP-5C | MSP-10C | MSP-15C | MSP-2E | MSP-5E | MSP-10E | MSP-15E |
| Operate | Key Operation | Knob operation | ||||||
| Heating Power(W) | 400W | 650W | 900W | 900W | 400W | 650W | 900W | 900W |
| Heating Plate Size (Mm) | 140mm*140mm | φ180mm | φ230mm | φ280mm | 140mm*140mm | φ180mm | φ230mm | φ280mm |
| Dimensions (Mm) | 300*170*100 | 350*205*100 | 400*260*110 | 450*290*110 | 300*170*100 | 350*205*100 | 400*260*110 | 450*290*110 |
| Motor Power (W) | 40W | |||||||
| Stirring Speed | 60～2000r/min | |||||||
| Speed Control Accuracy | ±5 r/min; Digital display | |||||||
| Temperature Control Range | Room temperature～350℃ | |||||||
| Temperature Control Accuracy | ±1 r/℃ Digital display | |||||||
| Furnace Wire | Cr20Ni80 | |||||||
| Working Hours | continuous | |||||||
| Basic Error Of Temperature Measurement | <0.5% | |||||||
| Speed Sensor | Hall element | |||||||
| Work Environment | Ambient temperature: -10～60℃; Relative temperature: <85%RH | |||||||
| Power Supply | AC220V±10% 50/60Hz | |||||||
